Microlift T20i – Hybrid Pallet Truck

Description

T20 is the real hybrid pallet truck.

  • Fully Electric – Totalmente Electrica
  • AC Brushless Motor (Manual/Electric Convertible) kills the downtime forever.
  • with Microlift through innovation to the future!
  • 4400lbs/5500lbs
  • Portable li-ion battery, 48V15Ah with 5A charger
  • 750w AC Brushless Driving motor
  • Marks on forks to help position the pallets precisely

Download Specs

Original price was: $3,250.00.Current price is: $2,875.00.

-

1ManufacturerMicrolift
2ModelT20i
3DriveElectric / Manual
4LiftElectric / Manual
5Operator typeWalkie
6Load CapacityQ2000kg (4400lbs)
7Load CenterC600mm (24")
8WheelbaseY1202mm/1272mm (47.3"/50.1")
9Service Weight135/140kg (297/308lbs)
10Overall Heighth1524mm (20.6")
11Fork Height (Lowered)h280mm (3.15")
12Lift Heighth3200mm (8")
13Tiller Arm Heighth4560mm~1280mm (22"~50.4")
14Ground Clearanceh527mm (1.1")
15Overall LengthL11546mm/1616mm (60.8"/63.6")
16Overall Widthb1540mm/680mm (21"/27")
17Fork SizeL1150mm/1220mm (45"/48")
S53mm (2.1")
e160mm (6.3")
18Turning Radius (Min.)Wa1352mm/1422mm (53.2"/56")
19Aisle width for pallets 1000x1200 crosswaysAST1980mm (78")
20Aisle width for pallets 800x1200 crosswaysAST1880mm (74")
21Drive Motor0.75kw Brushless
22Travel Speed (laden/unladen)4.5/4.8km/h (2.8/3.0mph)
23Max. Gradeability (laden/unladen)%8%/20%
24Brake ServiceElectromagnetic
25Lift Motor0.65kw
26Controller Manufacturer/TypeMICROLIFT i50
27Battery Voltage/CapacityV/Ah48V/20Ah Li-Ion
28ChargerA48V/10A (48V/4A option)
